JGINYUE B550M GAMING motherboard VGA version
Supports AMD AM4 4000 and 5000 series processors
Supports dual channel 2 DDR4 memory slots with a maximum capacity of 64GB
Memory frequency: 2133/2400/2666/2800/3000/3200/3333/3466/3600/3733/3866/4000MHz (supports XMP technology/actual situation may vary depending on different CPU and memory configurations)
Display interface: 1 HDMI, 1 DP interface, 1 VGA interface
4 SATA3.0, 1 M.2 NVME protocol interface (directly connected to CPU for automatic recognition 3.0 or 4.0), 1 M.2 NVME protocol 3.0 interface
4 USB 3.2 and 2 USB 2.0 in the rear; Front 1 USB 3.2 pin, 1 USB 2.0 pin
1 PCI Express x16 slot (directly connected to CPU automatically recognized by CPU)
  • Details Introduction
  • specification parameter
  • download
  • Motherboard model
  • B550M GAMING VGA version
  • Chipset
  • AMD B550 Chipset
  • CPU pins
  • Supports AMD AM4 4000 and 5000 series processors
  • Memory slot
  • 2 DDR4 memory slots
  • Memory capacity
  • Maximum support for 64G (32G * 2)
  • Memory frequency
  • Dual channel support 2133/2400/2666/2800/3000/3200/3333/3466/3600/3733/3866/4000MHz (supports XMP technology/actual situation may vary depending on different CPU and memory configurations)
  • Display interface
  • 1 HDMI, 1 DP, 1 VGA
  • Storage interface
  • 4 SATA3.0 6Gbps; 1 M.2 nvme protocol interface (directly connected to CPU for automatic recognition 3.0 or 4.0), 1 M.2 nvme protocol 3.0 interface
  • USB interface
  • 4 USB 3.2 and 2 USB 2.0 in the rear; 1 USB 3.2 pin in front can expand 2 USB 3.2 pins, and 2 USB 2.0 pins can expand 4 USB 2.0 pins
  • PCIe interface
  • 1 PCI Express x16 slot (directly connected to CPU automatically recognized by CPU), 1 PCI Express x1 slot
  • Wireless interface
  • 1 WiFi interface (compatible with PCIe protocol)
  • Onboard sound card
  • Realtek ALC897
  • Onboard network card
  • Realtek 8111H
  • Power supply socket
  • Main board 24Pin power supply, CPU 8Pin power supply
  • Fan pin
  • Two 4-needle, two 3-needle
  • Number of power supply phases
  • 10 phase power supply
  • PCB layers
  • 6-layer PCB
  • Size specifications
  • 24cmx22cm M-ATX
  • support system
  • Windows 10; Windows 11
  • Other interfaces
  • 1 one click BIOS clear button; PS/2 keyboard and mouse interface
Alsa
Software Download
BIOS
instruction book
    • FileVersion System Updated Date brief introduction download
    Realtek Audio Driver 6.0.9239.1 win10,win11 64 bits 2024-05-09 audio driver
    network_Realtek_w10_64 win10,win11 64 bits 2024-05-09 Network Driver
    FileVersion System Updated Date brief introduction download
    • FileVersion System Updated Date brief introduction download
    B550M GAMING win10&win11 2024-11-07 Fixed graphics card at PCIe 3.0 rate
    B550M GAMING Motherboard BIOS file win10,win11 64 bits 2024-03-05 Mass production BIOS files
    FileVersion System Updated Date brief introduction download
